By default, an element's width and height are as wide or as tall as the content it holds. But we're able to set our own dimensions with the width and height properties.
[MUSIC]
0:00
So, now let's see how everything we've
learned so
0:04
far about the box model applies to
building a basic layout.
0:07
So, by default, an element's width and
height are as wide or
0:11
as tall as the content it holds.
0:15
But we're also able to set our own
dimensions using the width and
0:18
height properties.
0:21
Now, the width and height properties can
accept length units such as pixels,
0:23
ems, or percentages and their values.
0:28
In the previous stage, we learned that
when we use a percentage value for
0:30
width, the width is measured relative to
the parent element's width.
0:35
So, the 60% width value we gave our
primary and secondary-content
0:38
divs earlier adjust based on the parent
body element, which is 100% by default.
0:45
But pixel values are still commonly used
for layout because, as we've learned in
0:52
previous videos, they allow us precise
control over the size of an element.
0:56
For instance, you'll notice this large
arrow image in our header.
1:02
Now, the arrow image is embedded as an
SVG, or Scalable Vector Graphics.
1:07
So, we'll need to scale it down with a
width property.
1:12
So, let's give the image element on line
ten a class of arrow.
1:15
So, now let's save our index.html file and
go back to our style sheet.
1:23
And all the way at the bottom underneath
the wildlife rule, let's go ahead and
1:28
target that new arrow class.
1:32
And we're gonna give our arrow rule a
width property, and
1:37
let's set the value to 50 pixels.
1:41
So let's save our style sheet, and
1:45
go back to the browser preview and refresh
the page.
1:46
So, now we can see how our arrow image is
now
1:50
scaled down to 50 pixels wide while
maintaining its proportions.
1:53
So, next for our Lake Tahoe page design,
1:59
we'll want to increase the height of our
main header element.
2:02
So, let's do that with a height property.
2:05
We'll go back to our style sheet, and
2:08
let's scroll up to the main header rule
right here under Main Styles.
2:10
And right beneath the background-color
property, let's add a height property.
2:16
And we're going to set the height value to
850 pixels.
2:21
All right, so let's take a look.
2:25
We'll save our style sheet and refresh the
page, and
2:26
now we see how our header is much taller.
2:30
And we're going to use this space later
when we
2:33
add a nice background image to our header.
2:36
Keep in mind that when a width or height
is defined on a element, we're not exactly
2:39
defining the entire area of the box,
meaning the content, padding and borders.
2:43
We're actually just defining the width for
the content area itself, and
2:49
this can actually create some issues,
especially when building layouts.
2:53
I'll show you what I mean.
2:56
So, let's go back to our main header rule,
and we're gonna add a padding-top
2:58
property, and we're going to set the top
padding to 170 pixels.
3:03
Now, when we add the top padding,
3:09
notice how the height of the header
increases by 170 pixels.
3:12
And if we once again open up our Chrome
developer tools by clicking the right top
3:18
icon menu here, then highlighting More
tools, then clicking Developer tools,
3:23
when we inspect the height of our header,
notice how instead of being 850 pixels
3:29
tall like we need it to be, our header's
actually 1,020 pixels tall.
3:35
Well, that's happening because the
browser, based on the box model,
3:40
calculates a total height value by taking
the height value we define and
3:44
adding the padding-top value and any
padding-bottom or any top and
3:50
bottom border styles we define.
3:54
So, if we were to add borders to our
header or
3:56
bottom padding, the total height would
increase based on those additional values.
3:59
And if we scroll down, we're also seeing
that happening in our wildlife container.
4:03
The top border and
4:08
padding values are increasing of the total
height of the element.
4:09
And the same issue that happens with
height also happens with
4:14
the total width value of an element.
4:17
And this can make our layout elements
wider than they need to be.
4:19
I'll show you a good example of this.
4:22
So first, let's go back to our style
sheet, and let's find our primary and
4:24
secondary-content rules right here under
Layout Styles.
4:29
And let's set their width back to a fixed
width of 960 pixels.
4:34
So, we're going to replace the 60% width
value to 960 pixels.
4:39
So now if we save our style sheet and
refresh the browser,
4:45
we can see that our secondary and
primary-content is our 960 pixels wide.
4:49
But now, we'll want to add left and right
padding to the content divs just to
4:55
have a little separation between the
content page and the margins.
5:00
So, let's go back to our primary and
secondary-content rule, and
5:05
right beneath the width property, let's
add a padding-left property,
5:09
and let's set the value to 50 pixels.
5:15
And right below that, let's add a
padding-right property, and
5:18
let's set the value to 50 pixels as well.
5:23
So now when we save our style sheet and
5:26
take a look at our layout, and refresh the
page, and once again,
5:29
use the dev tools to inspect the primary
or secondary-content containers,
5:33
notice how the total width now expands to
1,060 pixels wide.
5:38
It's adding 100 pixels to the total width
because we've added 50 pixels of
5:43
padding to the left and right sides of the
div.
5:48
So, like with the height property, the
browser calculates the total width value
5:52
by adding the width value we define with
any left or
5:58
right padding and border width values.
6:02
So, with all that being said,
6:04
what if we need these container divs to be
exactly the width and height we specified?
6:06
And we actually do in our case.
6:11
Well, we could do a bit of math and maybe
subtract the padding or
6:13
border widths from the total width or
height volume we defined.
6:18
For instance, instead of 960 pixels, we
can set the width value here
6:23
to 860 pixels to compensate for that extra
100 pixels of padding.
6:28
Well, sure, this works just fine, but
imagine having to do this for
6:33
every element in our layout that has a
width, height, or padding and
6:38
border width defined, right?
6:41
Well, in the next video, we're gonna learn
a better solution for this.
6:43
